Corne Cherry v3 Keyboard Kit

$59.00 USD

~~$0.00 USD~~ $59.00 USD

Sale Sold out

Taxes included. Shipping calculated at checkout.

Color (PCB/Switch Plate) Black White Purple

KEEBD - Keyboards, Cases, Switches, Parts and Accessories

Stock notification

Get an email when this product is back in stock.

Corne Cherry v3 Keyboard Kit

We respect your privacy and don't share your email with anybody.

...

The Corne keyboard is a split keyboard with 3x6 column staggered keys and 3 thumb keys, based on Helix.

Precompiled firmware can be found here.

Kit Includes

2 x FR4 Switch Plates

2 x Corne Cherry PCBs

2 x Acrylic Bottom Plates

2 x Acrylic OLED Covers

1 x TRS Cable

2 x TRRS Jacks

2 x 3x6 Tactile Switches

2 x OLED Displays

42 x Kailh Hotswap Sockets

42 x Diodes (SMD)

4 x 10mm Brass Standoffs

10 x 7mm Brass Standoffs

14 x 4mm Screws

14 x 6mm Screws

8 x Rubber Feet

Required to Complete

2 x Pro Micro Controllers (Headers to Direct Attach)

42 x MX Switches

42 x MX Keycaps (40 x 1u, 2 x 1.5u)

Optional Items

2 x EZ-Solder Headers (Enable Controller Hot Swap)
2 x 4Pin Header Socket (Enable Display Hot Swap)
42 x SK6812mini-E LED Per Key Lights

12 x WS2812B LED Rear Facing Drop Lights

Build Instructions

Corne Cherry v3 RGB Build Guide

This keyboard is designed by Foostan

View full details

Excelent service and components

I’ve been able to build the keyboard without any problems

Difficult but good kit

Took me over 10 hours to complete, and then 3 hours resoldering and debugging the displays not working. But the issues were all caused by inexperience (and the precompiled Mikoto controller firmware not working for the displays).

It's now fully functional, and I'm very happy with it. Though I do wish I'd gotten the hot-swappable display adapters.

Very happy with the keybaord

Other than a few parts missing (witch were deliverd quickly and in a timely manner, after mailing the sales team) everything was awsome, assembly was fun and I am very happy with they keyboard
